SILA Embedded Solutions GmbH
CC-Link IE TSN software development kit for remote stations is provided as portable C source code with sample applications for STM32. A unified porting layer allows easy adaption of the stack to customer specific hardware. The SDK is selfcontained and no further costs are involved for development of a CC-Link IE TSN remote station.
Developable Stations / Certification Classes
| Development tool | Station type | Certification class | Product name |
|---|---|---|---|
| Software Development Kit (SDK) | Remote station | Class B | CC-LINK IE TSN STM32 Coming soon |
Development Method
The SDK is self-contained and evaluation can
easily be performed on the STM32 NUCLEO
evaluation board as provided by numerous 3rd
party vendors.
- Remote device application development can be started on the evaluation boards using the provided CSP+ files and examples for GX Works3. Other masters will be supported in future demos.
- If hardware and software environment is similar to the demos, they can be used for your own software development. Otherwise, the demos can serve as a starting point to adapt the port to new RTOS and/or hardware platforms.
- Embedded Experts GmbH, a SILA subsidiary, also provides porting services to existing or new customer hardware.To further support development, the SDK includes a combined getting started and porting manual.To further support development, the SDK includes a combined getting started and porting manual.
To further support development, the SDK includes a combined getting started and porting manual.
Features and benefits of development methods
Features:
- Delivered as C source code
- Supports STM32
- TSN ready
- Use hardware MAC support for IEEE 802.1AS and IEEE 1588v2 if available.
- Software 802.1Qbv implementation
- Complete with OS, TCP/IP stack, documentation and samples to reduce development time.
| STM32 | |
|---|---|
| OS | FreeRTOS |
| IDE | STM32CubeIDE or GCC + CMAKE based |
| TCP/IP stack | lwIP |
| Devices | STM32F769 |
| TSN | IEEE 802.1AS + IEEE 1588v2 IEEE 802.1Qbv |
| Ethernet ports | 1 (Star)/td> |
| Speed | 100 Mbit/s |
Contact Information
Linzerstrasse 28, Sankt Pölten, 3100, Austria
TEL/FAX:+43-2742-93084
URL：http://www.embedded-solutions.at
E-mail：
