Belden Hirschmann Industries（Suzhou）Ltd.

IE-M12XM-RJ45-xxM CC-Link IE Field Category 5e 1000 Mbps Double-Ended Cord set.

CC-Link IE Field Category 5e 1000 Mbps Double-Ended Cord set: Male straight X-coded black M12 standard to male straight black RJ45, shielded, PVC orange cable, 8 wires.

Feature

  • Cable Design: 4P CAT5e PE/OS/OBS/PVC Fixed LAN Cable
  • CC-Link IE Field Reference Number: NRT-IF-00041
  • Conductor Material: Solid Bare Copper
  • Insulation Material: Polyolefin
  • No. of Cores/Pairs (cable): 4 pairs
  • Shielding Type: Al-Mylar + Braid
  • Shielding Material: Tinned Copper
  • Outer Jacket Material: PVC
  • Overall Diameter (mm): Nom. 6.70 mm
  • Operational Temperature: -30°C to + 75°C
  • Oil resistance: Yes
  • UV/Sunlight resistance: Yes
  • Flame Retardant: IEC 60332-1, UL 444 (CM)
  • Maximum operating voltage (V): 300 V
  • Characteristics Impedance (MΩ.km): 100 ± 15 MΩ.km
  • RoHS Compliant: Yes
  • For Connector Type: M12 Standard
    Data Transmission: 1000 Mbit/s
    Connector Pins: 8
    Coding: X-coded
    Contact Resistance: ≤ 10 mOhm
    Insulation Resistance: > 10ᶺ8 Ohm
    Mating Cycles: ≤ 100
    Protection Degree / IP Rating: IP65 & IP67
    Contact plating: Cu/Au
    Flammability class (Contact Bearer): UL 94 V-0 rated
    Flammability class (Moulded Body): UL 94 HB rated
    Attachment Material: CuZn
    Attachment Plating: Nickel-plated
    Shielding Material: CuZn, tin-plated
    Fastening Torque (Attachment): M12x1: 50-60 N-cm, hand-tight
  • For Connector Type: RJ45 Male
    Data Transmission: 1000 Mbit/s
    Connector Pins: 8
    Protection Degree / IP Rating: IP20
    Shielding material: Copper alloy
    Plug Housing Material: PC - Polycarbonate, UL94 V-0 rated
    Attachment Plating: Gold plating in contact area
Type of station or product category
Maximum transmission distance
Outside diameter/External dimensions
Mass
Standard Price
