Sanitary Manufacturing Equipment
Chan Li Machinery
CC-Link IE TSN Class A enables network integration. It reduces maintenance work time and can flexibly respond to system upgrades.
2024年 10月
System Configuration
According to customers' requirement to design a single paper stand or double paper stand. Automatic paper core change, tail trimming, gluing and sealing.Optional single embosser, double embosser, point to point mbosser, edge embosser, lamination and printing equipment for different kinds of products.Special spiral perforator design to minimize the perforating noise and get long life time.
Key Points
- 1.All equipment is customized, and different process equipment can be added according to customer needs in the future.
- 2.One network can connect all FA products and Ethernet devices.
- 3.Adopt CC-Link IE TSN Class A, star topology.
- 4.When using multiple inverters, you can easily set and manage the parameters of the inverters, reducing startup and maintenance work time.
- 5.When adding new process equipment, the same network integrated control system can be used.
