Conformance Test

All of CC-Link Family certified products sold by partner-manufacturers have passed conformance tests to ensure compatibility.

Conformance test objectives

CC-Link Partner Association conducts conformance tests on all certified products based on the specifications defined by CLPA to ensure that the products fulfill the communication specifications and connectivity.
Test tools are available for CC-Link IE Field Netwolk Basic and SLMP.

Benefits

Ensures the communication reliability of the product.
Enables flexible system configuration by ensuring interoperability across manufacturers and models.

Conformance
test items
  • Hardware test
  • Software test
  • Profile description (CSP+) confirmation
  • Aging test

*Please refer to the applicable Conformance Test Specifications for details (members only).

Test cases

Power supply noise test (AC/DC)

Power supply noise test (AC/DC)

Communication line noise test

Communication line noise test

Aging test

Aging test

Test items and divisions of responsibility

Test items include items to be performed by the partner manufacturer in advance and items to be performed by CLPA. Some items are tested by both the partner manufacturer and CLPA.
All test items at the partner manufacturer must be passed before testing at CLPA.

attention

Caution

  • The conformance test is intended to assure that the product meets CC-Link IE TSN communication specifications, and not intended for device-specific functions.
  • Passing the conformance test does not mean that the performance or quality of the product itself are guaranteed.
  • Recommended wiring parts test can be applied to Ethernet Switches, cables, connectors, etc.

Workflow for conformance testing

Workflow for conformance testing

CC-Link Conformance Test Regulation

Available for download to Regular members, Executive members, and Board members.

Related Menus

Click here for downloads

Conformance Test Fee

"CLPA Membership" and "Rights and Fees by Membership Category"

(Tax not included)
Rights and Fees Membership Categories Remarks
Registered
Member		 Regular
Member		 Executive
Member		 Board
Member
The right to obtain the CC-Link Family specifications free of charge Yes
  • - Provided for free.
  • - Conformance test specifications are available for Regular members and above.
The right to develop, manufacture and sell CC-Link Family products, development tools and recommended-wiring products No Yes This is the right granted to developers and/or Member manufacturers. It does not regulate the resale of products by distributors.
The right to use the CC-Link Family technology No *1 Yes
The right to use the CC-Link Family logo No *2 Yes
The right to publish the information about the Member's own product on the CLPA Global Website. No Yes Published for free
Annual Fees
Amount of money in ( ) shows monthly fees for intermediate enrollment.		 Not charged
(free)		 100,000 yen
(9,000 yen)		 200,000 yen
(18,000 yen)		 1 million yen
(84,000 yen)		 According to the bill issued by CLPA
Initial Fee Not charged (free) 1 million yen According to the bill issued by CLPA
Conformance Test Fees
(per product) 		CC-Link IE TSN
  • - Manager/
    Local Station
    　
  • - Remote Station
  • - Development tool
 N/A 100,000 yen 50,000 yen Not charged
(free)		 According to the bill issued by CLPA
  • - Drive profile Compatible
 N/A 100,000 yen 50,000 yen Not charged
(free)		 According to the bill issued by CLPA
CC-Link IE Control Network
  • - Normal Station
  • - Control Station
  • - Development tool
 N/A 400,000 yen 300,000 yen Not charged
(free)		 According to the bill issued by CLPA
CC-Link IE Field Network
  • - Manager/
    Local Station
  • - Intelligent Device Station
  • - Development tool
 N/A 400,000 yen 300,000 yen Not charged
(free)		 According to the bill issued by CLPA
CC-Link IE Field Network Basic
  • - Manager/
    Remote station
  • - Development tool
 N/A 100,000 yen 50,000 yen Not charged
(free)
  • - According to the bill issued by CLPA
  • - Download the test tools and conduct test
CC-Link IE Safety Communication Function
  • - IESMAP
  • - IESSLP
  • - Development tool
 N/A 300,000 yen 200,000 yen Not charged
(free)		 According to the bill issued by CLPA
CC-Link
  • - Remote Device Station
  • - Remote I/O Station
  • - Cable
  • - Development tool
 N/A 300,000 yen 200,000 yen Not charged
(free)		 According to the bill issued by CLPA
  • - Manager/
    Local Station
  • - Intelligent Device Station
  • - Development tool
 N/A 400,000 yen 300,000 yen Not charged
(free)
CC-Link/LT
  • - Manager Station
  • - Remote I/O Station
  • - Cable
  • - Development tool
 N/A 300,000 yen 200,000 yen Not charged
(free)		 According to the bill issued by CLPA
SLMP
  • - Client
  • - Server
 N/A 100,000 yen 50,000 yen Not charged
(free)
  • - According to the bill issued by CLPA
  • - Download the test tools and conduct test
Recommended-wiring Product Test Fees
(per product) 		CC-Link IE TSN
  • - Cables
  • - Connectors
  • - Switches
  • etc.
 N/A 100,000 yen 50,000 yen Not charged
(free)		 According to the bill issued by CLPA
CC-Link IE Control Network
  • - Cables
  • - Media converters
  • etc.
 N/A 150,000 yen 100,000 yen Not charged
(free)		 According to the bill issued by CLPA
CC-Link IE Field Network
  • - Cables
  • - Connectors
  • - Switches
  • etc.
 N/A 150,000 yen 100,000 yen Not charged
(free)		 According to the bill issued by CLPA
Tool Test Fees
(per product)		 CC-Link IE TSN
  • - Software
  • etc.
 N/A 100,000 yen 50,000 yen Not charged
(free)		 According to the bill issued by CLPA
  • *1:As long as it does not conflict with the rights of other partners, you may use the logo for promotional purposes only.
